Ordinary Thimble

Product Description

Ordinary Thimble NOMINAL SIZE OF ROPE A B *C Min D E *F Min G r1 J APPROX K L 8 22 38 13 9 4 3.5 62 4 30 10 24 46 15 11 6 5.5 76 5 34 12 32 60 19 13 8 7.5 90 6 44 14 32 60 21 15 8 7.5 90 6 44 16 40 72 23 17 8 7.5 114 8 56 18 44 80 29 19 10 9.5 125 8 60 20 50 94 31 21 12 11 150 10 70 22 58 102 34 24 121 11 165 10 78 24 64 108 36 26 12 11 176 10 84 25 70 118 37 27 14 13 200 10 90 29 76 132 41 31 16 14.5 230 12 100 32 96 152 44 34 16 14.5 250 12 120 35 104 174 48 38 19 17.5 300 16 136 38 114 198 54 41 24 22 330 18 150 41 114 198 56 165 254 44 24 22 330 18 150 44 125 222 57 178 285 47 26 23.5 355 25 175 48 134 246 67 190 315 51 28 25.5 380 28 190 51 140 256 70 330 330 55 30 27.5 400 28 196 54 140 256 70 200 330 58 30 27.5 400 28 196 57 146 270 76 216 355 61 3 2 29.5 425 30 206 64 156 308 95 240 400 69 44 41 450 32 220 70 200 400 120 275 500 75 60 57 480 40 280 Note For wire ropes of intermediate size, the next larger size of thimble shall be used. These dimension are minimum for thimbles of nominal size up to and including 41 only
