Eye Hook for Wire Rope Application

Product Description

Eye Hook for Wire Rope Application1) The most complete line of Eye hooks. Available ton to 60 tons. 2) Properly designed, forged & heat treated to give maximum strength. 3) Every Eye Hook has a pre-drilled cam which can be equipped with a latch. 4) Eye hooks are load rated. 5) Available in mild steel and alloy steel. WORKING LOAD LIMIT (tons) DIMENSIONS (mm) CARBON ALLOY A B C D F G H J K P Q 8 1.25 110 37.3 81.5 73 31.8 19.1 20.1 20.1 14.2 51 19 1 1.6 125 44.5 93.5 81 35.1 21.3 23.9 23.9 15.8 57 23.1 1.6 2.5 141 51.5 104 92 38.1 25.4 29.5 29.5 19.1 64 28.7 2 3.2 162 61 119 104 41.4 28.5 33.3 33.3 21.3 72 31.8 3.2 5.4 201 74.5 147 125 51 36.6 41.2 41.2 28.5 90.5 39.6 5 8 256 97 187 165 63.5 46 52 52 35.1 113 51 7.5 12.5 316 119 230 192 76 57 66.5 66.5 41.2 140 62 10 16 354 137 255 221 82.5 65.5 74.5 74.5 49.3 157 72 15 22 434 168 318 279 108 75.5 89 89 60.5 186 89 20 30 495 178 357 346 127 92 117 117 76 223 89 25 37 630 216 462 357 137 116 127 127 92 289 114 30 45 697 236 511 392 152 129 140 140 94.5 321 125 40 60 821 273 602 470 178 152 165 165 113 376 145 Note 1) Proof load is 2 times Working Load Limit. 2) All carbon hooks have average straightening load (ultimate load) is 5 times Working Load Limit. 3) All Alloy hooks have average straightening load (ultimate load) is 4 times Working Load Limit
